How to Build a Production
RAG Pipeline in Python (2026)

Most RAG tutorials show you a working demo in 20 lines. This is not that guide. We cover what actually matters for production: chunking strategy, hybrid retrieval, reranking, and evaluation. These are the decisions that separate a demo that impresses in a slide deck from a system that handles real user queries reliably. For a deeper architecture overview, see our RAG architecture guide.

What Makes a RAG Pipeline "Production-Grade"

A production RAG pipeline differs from a prototype in four ways:

• Chunking strategy — chunk size and overlap affect retrieval precision more than almost any other variable
• Hybrid retrieval — combining dense vector search with sparse BM25 retrieval catches what either alone misses
• Reranking — a cross-encoder reranker dramatically improves the quality of the top-k passages fed to the LLM
• Evaluation — systematic measurement with RAGAS before and after every significant change

Install Dependencies

pip install qdrant-client openai cohere langchain langchain-openai \
            langchain-community rank-bm25 ragas datasets

Step 1 — Document Ingestion and Chunking

Chunk size is the most impactful early decision. Our benchmarks across four client deployments (support docs, legal contracts, technical manuals, sales playbooks) consistently found 512 tokens with 50-token overlap to be the best default. Smaller chunks (256 tokens) give higher retrieval precision but lower context richness. Larger chunks (1024 tokens) lose precision — the relevant sentence gets buried.

from langchain.text_splitter import RecursiveCharacterTextSplitter
from langchain_community.document_loaders import DirectoryLoader, PyPDFLoader

# Load documents
loader = DirectoryLoader("./docs", glob="**/*.pdf", loader_cls=PyPDFLoader)
documents = loader.load()

# Chunk with 512 tokens, 50-token overlap
splitter = RecursiveCharacterTextSplitter(
    chunk_size=512,
    chunk_overlap=50,
    length_function=len,
    separators=["\n\n", "\n", ". ", " ", ""],
)
chunks = splitter.split_documents(documents)

# Preserve metadata for filtering and citation
for i, chunk in enumerate(chunks):
    chunk.metadata["chunk_id"] = i
    chunk.metadata["source"] = chunk.metadata.get("source", "unknown")

print(f"Created {len(chunks)} chunks from {len(documents)} documents")

Step 2 — Embedding Model Setup

For most production use cases, OpenAI's text-embedding-3-small is the best balance of quality and cost — better than ada-002 at half the price. For cost-sensitive or data-sovereignty deployments, BGE-M3 (open-source, runs locally) is a strong alternative.

from openai import OpenAI
import numpy as np

client = OpenAI()

def embed_texts(texts: list[str], batch_size: int = 100) -> list[list[float]]:
    """Embed texts in batches to respect API rate limits."""
    embeddings = []
    for i in range(0, len(texts), batch_size):
        batch = texts[i:i + batch_size]
        response = client.embeddings.create(
            model="text-embedding-3-small",
            input=batch,
        )
        embeddings.extend([e.embedding for e in response.data])
    return embeddings

Step 3 — Setting Up Qdrant

Run Qdrant locally with Docker for development:

docker run -p 6333:6333 qdrant/qdrant

For production, use Qdrant Cloud or self-host on Kubernetes. Create a collection and index your chunks:

from qdrant_client import QdrantClient
from qdrant_client.models import Distance, VectorParams, PointStruct

qdrant = QdrantClient("localhost", port=6333)

COLLECTION = "knowledge_base"
VECTOR_DIM = 1536  # text-embedding-3-small dimension

# Create collection
qdrant.recreate_collection(
    collection_name=COLLECTION,
    vectors_config=VectorParams(size=VECTOR_DIM, distance=Distance.COSINE),
)

# Index chunks
texts = [chunk.page_content for chunk in chunks]
vectors = embed_texts(texts)

points = [
    PointStruct(
        id=i,
        vector=vectors[i],
        payload={
            "text": chunks[i].page_content,
            "source": chunks[i].metadata.get("source"),
            "chunk_id": chunks[i].metadata.get("chunk_id"),
        },
    )
    for i in range(len(chunks))
]

qdrant.upsert(collection_name=COLLECTION, points=points)
print(f"Indexed {len(points)} chunks")

Step 4 — Hybrid Retrieval (Dense + Sparse)

Pure dense vector search is good but misses exact keyword matches — acronyms, product names, version numbers. Sparse BM25 retrieval catches these. Combining both with Reciprocal Rank Fusion (RRF) gives you the best of both worlds.

from rank_bm25 import BM25Okapi
from collections import defaultdict

# Build BM25 index over your corpus
corpus = [chunk.page_content.lower().split() for chunk in chunks]
bm25 = BM25Okapi(corpus)

def hybrid_search(query: str, top_k: int = 20) -> list[dict]:
    """Combine dense and sparse retrieval with Reciprocal Rank Fusion."""
    query_embedding = embed_texts([query])[0]

    # Dense retrieval
    dense_results = qdrant.search(
        collection_name=COLLECTION,
        query_vector=query_embedding,
        limit=top_k,
    )
    dense_ids = [r.id for r in dense_results]

    # Sparse (BM25) retrieval
    bm25_scores = bm25.get_scores(query.lower().split())
    sparse_ids = sorted(range(len(bm25_scores)),
                        key=lambda i: bm25_scores[i], reverse=True)[:top_k]

    # Reciprocal Rank Fusion
    rrf_scores = defaultdict(float)
    k = 60  # RRF constant

    for rank, doc_id in enumerate(dense_ids):
        rrf_scores[doc_id] += 1 / (k + rank + 1)

    for rank, doc_id in enumerate(sparse_ids):
        rrf_scores[doc_id] += 1 / (k + rank + 1)

    # Return top-k by fused score
    top_ids = sorted(rrf_scores, key=rrf_scores.get, reverse=True)[:top_k]
    return [chunks[i].page_content for i in top_ids]

Step 5 — Reranking with Cohere

Retrieval returns candidates; reranking picks the best ones. A cross-encoder reranker like Cohere's rerank-english-v3.0 reads both the query and each passage together and scores relevance more accurately than the embedding-based similarity used in retrieval. Our benchmark finding: 256-token chunks with Cohere reranking consistently outperformed 1024-token chunks without reranking.

import cohere

co = cohere.Client("your-cohere-api-key")

def retrieve_and_rerank(query: str, top_k_retrieve: int = 20, top_k_final: int = 5) -> list[str]:
    """Retrieve candidates then rerank to final context."""
    candidates = hybrid_search(query, top_k=top_k_retrieve)

    rerank_response = co.rerank(
        model="rerank-english-v3.0",
        query=query,
        documents=candidates,
        top_n=top_k_final,
    )

    return [candidates[r.index] for r in rerank_response.results]


def answer(query: str) -> str:
    """Full RAG query: retrieve → rerank → generate."""
    context_passages = retrieve_and_rerank(query)
    context = "\n\n---\n\n".join(context_passages)

    response = client.chat.completions.create(
        model="gpt-4o-mini",
        messages=[
            {
                "role": "system",
                "content": (
                    "Answer the question using ONLY the context provided. "
                    "If the context does not contain enough information, say so. "
                    "Do not hallucinate facts not present in the context."
                ),
            },
            {
                "role": "user",
                "content": f"Context:\n{context}\n\nQuestion: {query}",
            },
        ],
        temperature=0.1,
    )
    return response.choices[0].message.content

Step 6 — Evaluation with RAGAS

Never ship a RAG system without first measuring it. RAGAS evaluates four dimensions that cover the most common failure modes. Build a test set of 50–200 representative questions with ground-truth answers before development starts.

from ragas import evaluate
from ragas.metrics import faithfulness, answer_relevancy, context_precision, context_recall
from datasets import Dataset

# Build evaluation dataset
eval_data = {
    "question": ["What is the refund policy?", "How do I reset my password?"],
    "answer": [],        # populated by your RAG system
    "contexts": [],      # list of retrieved passages per question
    "ground_truth": ["30-day full refund.", "Click 'Forgot password' on login page."],
}

for q in eval_data["question"]:
    passages = retrieve_and_rerank(q)
    response = answer(q)
    eval_data["answer"].append(response)
    eval_data["contexts"].append(passages)

dataset = Dataset.from_dict(eval_data)

result = evaluate(
    dataset,
    metrics=[faithfulness, answer_relevancy, context_precision, context_recall],
)

print(result)
# faithfulness: 0.91  ← target > 0.8
# answer_relevancy: 0.87  ← target > 0.8
# context_precision: 0.79  ← acceptable; below 0.7 needs retrieval tuning
# context_recall: 0.83  ← target > 0.8

A faithfulness score below 0.8 is a hard stop — it means the LLM is generating content not supported by the retrieved context (hallucination). Tune the system prompt and reduce generation temperature before shipping. For a deep dive on common production failures, see our guide on hybrid RAG for domain-specific LLMs.
